Muir HR1600 Cougar Compact Horizontal Windlass
- Rope chain combination gypsy for rope & chain combination or chain only
- Manual Override System (MORS)
- Gypsy lock / pawl
- Cleat on housing
- Heavy duty dual direction motor in 12 Vdc & 24 Vdc
- Durable marine grade white gloss finish alloy housing
- Fully enclosed motor & gearbox
- Independent gypsy and capstan operation
- Luxury chromed marine grade bronze / 316 Stainless steel running gear
- Stainless steel drive shaft
- Cone clutch/brake
- Shaft seal
- Clutch release handle
- Installation/Operation booklet
Vessel Length | 9 - 13 m (29 - 42 ft) |
Power Supply | 12 / 24 Vdc |
Motor | 1000 W |
Max Load | 545 kg (1200 lb) |
Work Load | 125 kg (275 lb) |
Amps Work Load | 100 / 60 |
Max Line Speed | 14.5 m / min (46 ft / min) |
Chain Size | 6 - 8 - 10 mm (1/4 - 5/16 - 3/8”) |
Rope Size | 12 - 14 - 16 mm (1/2 - 9/16 - 5/8”) |
Net Weight | 25 kg (55 lb) |
Manual Operation | MORS (Standard) |
